MBI1801 ∣Constant Current Linear LED Driver IC ∣ Automotive & General Lighting ∣ Macroblock



All-Ways-OnTM High-Power LED Driver

MBI1801 is an instant On/Off LED driver for high power LED applications and exploits PrecisionDrive™ and All-Ways-On™ technology to enhance its output characteristics. At MBI1801 output stage, one regulated current port is designed to provide a uniform and constant current sink for driving LEDs within a large range of VF variations. With All-Ways-On™, MBI1801 easily provides users a consistent current source.Users may adjust the output current from 50 mA up to 1.2A through an external resistor, Rext, which gives users flexibility in controlling the light intensity of LEDs.

In addition, users can precisely adjust LED brightness from 0% to 100% via output enable (/OE ) with Pulse Width Modulation. MBI1801 also guarantees that LEDs can be cascaded to maximum 17V at the output port. Additionally, MBI1801 is built with Thermal Protection (TP) function. The TP function protects IC from over temperature (165°C). Also, the TO package enhances the power dissipation. As a result, a large amount of current can be sunk safely in one package.

MBI1801 Specification

  • Items
  • 01
    No. of Output Channel
  • 02
  • 03
    Output Current per Channel
  • 04
    Sustaining Output Voltage
  • 05
    Excellent Output Current Accuracy-between channels
  • 06
    Excellent Output Current Accuracy-between ICs
    6% (Max.)
  • 07
    Supply Voltage
  • 08
    Dimming Method
  • 09
    Protection-LED Open/Short
  • 10
    Protection - Thermal Shutdown
  • 11
    Protection - Themal Error Flag
  • 12
    RoHS Compliant Package
  • 13
    Major Applications
    LED lighting, automotive lighting
