Product Guide
| Product No. |
|---|
| MBI6353 |
| MBI6349 |
| MBI6334 |
| MBI6329 |
| MBI6328 |
| MBI6323 |
| MBI6306 |
| MBI6304 |
| MBI5353 |
| No. of Output Channel | Output Current per Channel | Sustaining Output Voltage | Excellent Output Current Accuracy-between channels | Excellent Output Current Accuracy-between ICs | Scan Design |
|---|---|---|---|---|---|
| 48 | 4~100mA | 24V | <±3.0％ (max.) | <±3.0％ (max.) | Up to 4-scan |
| 26 | 5~30mA | 17V | <±2.0％ (max.) | <±2.0％ (max.) | Up to 8-scan |
| 64 | 5~30mA | 17V | <±3.0％ (max.) | <±3.0％ (max.) | Up to 8-scan |
| 48 | 4~40mA | 55V | <±3.0％ (max.) | <±3.0％ (max.) | Up to 8-scan |
| 48 | 4~40mA | 55V | <±3.0％ (max.) | <±3.0％ (max.) | Up to 8-scan |
| 32 | 2.2~46.3mA | 16V | <±2.0％ (max.) | <±2.5％ (max.) | Up to 16-scan |
| 6 | 0.1~10mA | 16V | <±2.0％ (max.) | <±3.0％ (max.) | |
| 4 | 3~70mA | 45V | <±2.0％ (max.) | <±3.0％ (max.) | |
| 48 | 0.5~20mA | 17V | <±1.5％ (typ.) | <±1.5％ (typ.) | Up to 32-scan |
| More Details |
|---|
 |
|
|
|
|
|
|
|
|
Application
| Application Category |
|---|
| Laptop, Tablet |
| Monitor, TV |
| CID |
| Features | IC Function |
|---|---|
| ● Slim & Stylish ● Low Power Consumption ● Support Gsync/Freesync |
● Time-multiplexing ● Power Switch Integration ● Voltage Feedback Control ● Variable Frame Rate Support ● Black Frame Insertion |
| ● High Dimming Zones ● HDR Performance ● Accurate Contrast ● Support Gsync/Freesync |
● Time-multiplexing ● High LED Voltage/ High LED Current ● Grayscale Accuracy ● Variable Frame Rate Support ● Black frame insertion |
| ● Image Quality ● Low Power Consumption ● AEC-Q100 Certified |
● Time-multiplexing Architecture for Local Dimming Design ● Dynamic Power-Saving ● Compact Package ● Pass AEC-Q100 |
| More Details |
|---|
|
|
|
