MBI6349 Specification

• Items
  Spec.
  Content
• 01
  No. of Output Channel
  26
• 02
  Output Current per Channel
  5~30mA
• 03
  Sustaining Output Voltage
  17V
• 04
  Excellent Output Current Accuracy-between channels
  <±2.0％ (max.)
• 05
  Excellent Output Current Accuracy-between ICs
  <±2.0％ (max.)
• 06
  Embedded MOSFET
• 07
  Transmission Interface
  SPI with Daisy Chain
• 08
  Transmission Method
  Burst Mode
• 09
  Scan Design
  Up to 8-scan
• 10
  Error Detection - LED Open
• 11
  Error Detection - LED Short
• 12
  Current Gain
  8-bit
• 13
  Dimming Method
  12-bit PWM
  12-bit PAM
• 14
  Dynamic-Sync
• 15
  Feedback Control
• 16
  Protection-OTP
• 17
  RoHS Compliant Package
  WLCSP-52 2.2x6
• 18
  Major Applications
  Laptop, Tablet
