Linear Regulator Product Guide
| Product No. |
|---|
| MBI1838 |
| MBI1828 |
| MBI1824 |
| MBI1816 |
| MBI1812 |
| MBI1804 |
| MBI1802 |
| MBI1801 |
| No. of Output Channel | Excellent Output Current Accuracy-between channels | Excellent Output Current Accuracy-between ICs | Output Current per Channel | Sustaining Output Voltage | Supply Voltage |
|---|---|---|---|---|---|
| 8 | 1% (Typ.) | 6% (Max.) | 80mA | 70V | 8-40V |
| 8 | 1% (Typ.) | 6% (Max.) | 60mA | 50V | 8-40V |
| 4 | 1% (Typ.) | 6% (Max.) | 120mA | 50V | 8-40V |
| 16 | 3% (Typ.) | 6% (Max.) | 60mA | 17V | 5V |
| 2 | 3% (Typ.) | 6% (Max.) | 360mA | 17V | 12V |
| 4 | 1% (Typ.) | 6% (Max.) | 240mA | 17V | 5V |
| 2 | 1% (Typ.) | 6% (Max.) | 40~360mA | 17V | 5V |
| 1 | 6% (Max.) | 50mA~1.2A | 17V | 5V |
| More Details |
|---|
 |
|
|
|
|
|
|
|
Application
| Application Category |
|---|
| LED Lighting/ Automotive Lighting |
| Features | IC Function |
|---|---|
| ● Instant Switch on and IC Control
● Adjustable Resistor to Change Current Output ● Set up LED Brightness by PWM ● Built-in Overheating Protection to Prevent IC Damage |
● High Brightness LED Driver IC |
