MBI1804

All-Ways-OnTM High-Power LED Driver

MBI1804 is an instant On/Off LED driver for high power LED applications and exploits PrecisionDrive™ and All-Ways-On™ technology to enhance its output characteristics. At MBI1804 output stage, four regulated current ports are designed to provide uniform and constant current sinks for driving LEDs within a large range of VF variations.

With All-Ways-On™, MBI1804 provides users 4-channel constant current ports. Users may adjust the output current from 40 mA up to 240mA through an external resistor, Rext, which gives users flexibility in controlling the light intensity of LEDs. In addition, users can precisely adjust LED brightness from 0% to 100% via output enable (/OE) with Pulse Width Modulation.

Additionally, to ensure the system reliability, MBI1804 is built with TP (Thermal Protection) function and thermal pad. The TP function protects IC from over temperature (165°C). Also, the thermal pad enhances the power dissipation. As a result, a large amount of current can be handled safely in one package.

MBI1804 Specification

  • Items
    Spec.
    Content
  • 01
    No. of Output Channel
    4
  • 02
    Topology
    Linear
  • 03
    Output Current per Channel
    240mA
  • 04
    Sustaining Output Voltage
    17V
  • 05
    Excellent Output Current Accuracy-between channels
    1% (Typ.)
  • 06
    Excellent Output Current Accuracy-between ICs
    6% (Max.)
  • 07
    Supply Voltage
    5V
  • 08
    Dimming Method
    Digital
  • 09
    Protection-LED Open/Short
  • 10
    Protection - Thermal Shutdown
  • 11
    Protection - Themal Error Flag
  • 12
    RoHS Compliant Package
    SOP8
  • 13
    Major Applications
    LED lighting, automotive lighting
