MBI1838 is an instant On/Off LED driver for LED automotive lighting and backlighting applications and exploits PrecisionDrive™ technology to enhance its output characteristics. At MBI1838 output stage, 8 regulated current ports are designed to provide uniform and constant current sinks for driving LEDs within a large range of VF variations, and in order to eliminate the heat generated by VF variations, a feedback function is integrated in MBI1838 to control the LED power source.
MBI1838 provides 8-channel constant current ports to match LEDs with equal current. Users may adjust the output current from 15mA to 80mA through an external resistor, Rext, which gives users flexibility in controlling the light intensity of LEDs. In addition, users can precisely adjust LED brightness from 0% to 100% via output enable pin (OE) with pulse width modulation signal.
MBI1838 can detect the error status of LED open-circuit, short-circuit, and the over temperature during the operation, and the pins, /ERR and /TH report these fault conditions. When LED open-circuit or short-circuit faults happen, only the faulted channel will be shut down to avoid affecting other normal channels. MBI1838 will disable all the output channels until the junction temperature is lower than the hysteresis, if the over temperature status occurs.
Additionally, to ensure the system reliability, MBI1838 is built with thermal pad which enhances the heat dissipation.
MBI1838 Specification
-
ItemsSpec.Content
-
01No. of Output Channel8
-
02TopologyLinear
-
03Output Current per Channel80mA
-
04Sustaining Output Voltage70V
-
05Excellent Output Current Accuracy-between channels1% (Typ.)
-
06Excellent Output Current Accuracy-between ICs6% (Max.)
-
07Supply Voltage8-40V
-
08Dimming MethodDigital
-
09Protection-LED Open/Short
-
10Protection - Thermal Shutdown
-
11Protection - Themal Error Flag
-
12RoHS Compliant PackageTSSOP24
-
13Major ApplicationsLED lighting, automotive lighting
