Interior Light

● Hysteretic PFM
Hysteretic PFM control with fast response provides high dimming resolution.

● Adequate Protection
    1. Techniques of failure protection including open/short-circuit, LED over current, over-temperature, and thermal fold back.
    2. Extend protection over power system failure to production failure.

● Thermal Fold-back
The LED driver IC providing thermal foldback function coupled with the thermistor should have the capability to resolve the self-heating issue of the thermistor. In addition, the most important capability is the adjustability of the thermal foldback curve which include output current break point temperature (TFB) and cut-off temperature (T Cut-off) capable of arbitrarily adjusting the thermal foldback function with circuit design.

● Pass AEC-Q100
AEC-Q100 Grade 1certified.

Interior Light Recommended Driver ICs

  • Product No.
    Max. Output Current per Channel
    Max. Sustaining Voltage
    More Details
  • MBI6657Q
