MBI5864

48-Channel PWM Constant Current LED Driver with Embedded Power Switch for 1:64 Time-multiplexing Applications

MBI5864 Specification

Items

Spec.

Content
01

LED Type

Common anode
02

Scan Type

Scan-sharing
03

No. of Output Channel

48
04

Output Current per Channel

0.1~5mA
05

Sustaining Output Voltage

7V
06

Excellent Output Current Accuracy-between channels

<±1％ (typ.)
07

Excellent Output Current Accuracy-between ICs

<±1％ (typ.)
08

Embedded MOSFET

16
09

Scan Design

Up to 64-scan
10

Error Detection - LED Open
11

Error Detection - LED Short
12

LED Failure Prediction
13

Current Gain

Global/RGB
14

PWM Enhancement
15

GCLK Multiplier
16

Intelligent Power Saving
17

S-PWM

13/14/15/16-bit
18

7 Challenges - Ghosting Elimination
19

7 Challenges - High Contrast Interference Elimination
20

7 Challenges - Color Shift Elimination
21

7 Challenges - Non-uniformity (IC Controlled)Elimination
22

7 Challenges - Dim Line at the First Line Elimination
23

7 Challenges - Gradient Dim Line Elimination
24

7 Challenges -Dead Pixel Isolation
25

RoHS Compliant Package

QFN88
BGA90
26

Major Applications

Time-multiplexing LED display

Hawkeye Solution Platform

NO.

Category / Solution

Features
Hawkeye 350-MBI5864

mini-LED/ micro-LED

0.4mm~1mm
