MBI5780 (Patented) 產品規格

• Items
  Spec.
  Content
• 01
  LED Type
  Common cathode
• 02
  Scan Type
  Scan-sharing
• 03
  No. of Output Channel
  48
• 04
  Output Current per Channel
  0.1~15mA
• 05
  Sustaining Output Voltage
  7V
• 06
  Excellent Output Current Accuracy-between channels
  <±1.0％ (Max.)
• 07
  Excellent Output Current Accuracy-between ICs
  <±1.0％ (Max.)
• 08
  Embedded MOSFET
  20
• 09
  Scan Design
  Up to 90-scan
• 10
  Error Detection - LED Open
• 11
  Error Detection - LED Short
• 12
  Error Detection-LED Pixel Short
• 13
  LED Failure Prediction
• 14
  Current Gain
  Global/ RGB
• 15
  PWM Enhancement
• 16
  GCLK Multiplier
• 17
  Intelligent Power Saving
• 18
  S-PWM
  14/15/16-bit
• 19
  7 Challenges - Ghosting Elimination
• 20
  7 Challenges - High Contrast Interference Elimination
• 21
  7 Challenges - Color Shift Elimination
• 22
  7 Challenges - Non-uniformity (IC Controlled)Elimination
• 23
  7 Challenges - Dim Line at the First Line Elimination
• 24
  7 Challenges - Gradient Dim Line Elimination
• 25
  7 Challenges - Dead Pixel Isolation
• 26
  RoHS Compliant Package
  QFN88
• 27
  Major Applications
  Time-multiplexing LED display
