Name: 車用照明暨顯示驅動晶片
Brand: 聚積科技 Macroblock

Topology	Max. Sustaining Voltage	Supply Voltage	Dimming Method
Multi-topology	71V	5.4~65V	Digital/Analog
Multi-topology/ Const. Frequency	65V	6~65V	Digital/ Analog
Buck/ Const. Frequency	50V	5~45V	Digital/ Analog
Buck	45V	6~40V	Digital/ Analog
Linear	28V	6~24V	Digital
Linear	50V	6~50V	Digital/Analog Built-in Pattern

No. of Output Channel	Output Current per Channel	Sustaining Output Voltage	Scan Design
48	4~100mA	24V	Up to 4-scan
48	4~100mA	24V	Up to 4-scan
6	0.1~10mA	16V
48	2~20mA	17V	Up to 32-scan

No. of Output Channel	Output Current per Channel	Sustaining Output Voltage	Scan Design
48	4~100mA	24V	Up to 4-scan
48	4~100mA	24V	Up to 4-scan
6	0.1~10mA	16V
24	4~72mA	13V	Up to 8-scan

No. of Output Channel	Output Current per Channel	Sustaining Output Voltage	Scan Design
48	0.1~15mA	7V	Up to 90-scan
48	2~20mA	17V	Up to 32-scan
48	2~20mA	17V	Up to 32-scan
16	2.0A

特色	晶片具備的功能
● 多重拓樸控制 ● 錯誤回報 ● 取得AEC-Q100認證	● 升壓/降壓/升降壓 ● LED 開路/LED 短路 ● 高效率 ● 通過 AEC-Q100
● 高效率 ● 可使用較少的EMI防治元件，降低EMI成本 ● 先進熱保護功能 ● 取得AEC-Q100認證	● 遲滯控制 ● 完善保護功能 ● 熱折返 ● 通過AEC-Q100
● 高效率 ● 可使用較少的EMI防治元件，降低EMI成本 ● 先進熱保護功能 ● 取得AEC-Q100認證	● 遲滯控制 ● 完善保護功能 ● 熱折返 ● 通過AEC-Q100
● 畫面品質 ● 低功耗 ● 取得AEC-Q100認證	● 針對區域調光之掃描架構 ● Dynamic 智慧節能 ● 精簡封裝 ● 通過 AEC-Q100
