MBI5981 is a specific power switch for scan type common cathode LED display. It has eight output channels, operates from 5V to 3.3V, and supports 2.5A maximum output current per channel. Moreover, MBI5981 has an internal circuit to eliminate ghosting which are a common problem of scan type LED displays.
MBI5981 Specification
-
ItemsSpec.Content
-
01No. of Output Channel8
-
02Output Current per Channel2.5A
-
03MOSFET TypeNMOS
-
04Operation Voltage3.3V~5V
-
05ON Resistance130m ohm
-
06High Contrast Interference Elimination
-
07Upper Ghosting Effect Elimination
-
08LED Short - Caterpillar Elimination
-
09RoHS Compliant PackageSOP16
QFN16 -
10Major ApplicationsFor common cathode LED driver
Hawkeye Solution Platform
-
NO.Category / SolutionFeatures
-
Hawkeye 200-MBI5762Common Cathode Fine Pitch0.9mm-4mm
-
Hawkeye 150-MBI5754Common Cathode Fine Pitch0.9mm~4mm
