DaVinci-MBI5762 Specification

• Items
  Spec.
  Content
• 01
  Solution
  Common Cathode Fine Pitch
• 02
  Driver IC
  MBI5762 (Patented)

• 03
  MOSFETs
  MBI5981

• 04
  Recommended Pixel Pitch Range
  0.8mm-2.6mm
• 05
  S-PWM
  Max. 16-bit
• 06
  DaVinci Premium Feature
  * Adaptive Refresh
  * Low-gray Refresh 2x-32x
• 07
  Superior Image Quality
  Solving the Seven Common Problems for Fine Pitch LED Display:
  1. Ghosting Effect
  2. Color Shift at Low Grayscale
  3. Non-uniformity at Low Grayscale
  4. Dim Line at the First Scan Line
  5. Gradient Dim Line
  6. LED Dead Pixel
  7. High Contrast Interference
• 08
  Scan Design
  Up to 32-scan
• 09
  Intelligent Power Saving
  Dynamic+
• 10
  Board Layout
  Simplified
• 11
  Output Current
  0.5mA-10mA
