MBI6033 ∣ RGB LED Driver IC ∣ Architecture Lighting- LED Strip, Mesh Display ∣ Macroblock



PWM-Embedded 3x4-Channel Constant-Current Sink Driver for LED Strips

MBI6033 is a 3x4-channel, constant-current, PWM-embedded sink driver for LED strips. MBI6033 provides constant current ranging from 3mA to 45mA for each output channel and are adjustable through only single external resistor and corresponding current gain settings. Besides, MBI6033 supports 6~24V wide range power systems and sustains 28V at output channels.

With Scrambled-PWM (S-PWM) technology, MBI6033 enhances pulse width modulation by scrambling the “on” time into several “on” periods to increase visual refresh rate at the same gray scale performance. Besides, the gray scale clock (GCLK) is generated by the embedded oscillator. Moreover, MBI6033 provides 16-bit gray scale which provides 65,536 gray scales for each LED to enrich the color.

3 independent 7-bit current gain settings are built-in MBI6033, so the user can set independent output current for R/G/B LED by a single current set resistor and current gain instead of 3 current set resistors.

In addition, MBI6033 features a two-wire transmission interface to make cluster-to-cluster connection easier. To improve the transmission quality, MBI6033 provides phase-inversed output clock to eliminate the accumulation of signal pulse width distortion. MBI6033 adopts manual-synchronization to maintain the synchronization of image frames between ICs.

MBI6033 Specification

  • Items
  • 01
    No. of Output Channel
  • 02
    Sustaining Output Voltage
  • 03
    Supply Voltage
    3~5.5V / 6~24V
  • 04
    Transmission Interface - Topology
  • 05
    Transmission Interface - Clock Integrity
    Clock Inversion
  • 06
    Transmission Interface - Bi-directional
  • 07
    Constant Output Current Range per Channel
  • 08
    Built-in LDO
  • 09
    Error Detection - LED Open
  • 10
    Error Detection - LED Short
  • 11
    Error Detection - Wire Disconnection
  • 12
    Thermal Protection
  • 13
    Current Gain
  • 14
  • 15
    Dot Correction
  • 16
  • 17
    RoHS Compliant Package
  • 18
    Major Applications
    LED strip, mesh display
