Macroblock’s Common Cathode Driving Architectures are Patented in the US
Patent no.: US 11,132,940,B2;
Patent no.: US 11,132,939,B2;
You can use Patent Public Search Basic of USPTO for more details
The display performance is upgraded to 16-bit grayscale∣7,680Hz refresh rate
------------------------------------------------------------------------------------------------------------------------------------------
MBI5762 (Patented) Specification
-
ItemsSpec.Content
-
01LED TypeCommon cathode
-
02Scan TypeTypical
-
03No. of Output Channel48
-
04Output Current per Channel0.5~10mA
-
05Sustaining Output Voltage7V
-
06Excellent Output Current Accuracy-between channels<±2.0％ (typ.)
-
07Excellent Output Current Accuracy-between ICs<±2.5％ (typ.)
-
08Embedded MOSFET
-
09Scan DesignUp to 32-scan
-
10Error Detection - LED Open
-
11Error Detection - LED Short
-
12Current Gain7-bit
-
13PWM EnhancementPLUS
-
14GCLK Multiplier
-
15Intelligent Power Saving
-
16S-PWM13/14/15/16-bit
-
177 Challenges - Ghosting Elimination
-
187 Challenges - High Contrast Interference Elimination
-
197 Challenges - Color Shift Elimination
-
207 Challenges - Non-uniformity (IC Controlled)Elimination
-
217 Challenges - Dim Line at the First Line Elimination
-
227 Challenges - Gradient Dim Line Elimination
-
237 Challenges -Dead Pixel Isolation
-
24RoHS Compliant PackageQFN64
-
25Major ApplicationsTime-multiplexing LED display
DaVinci Series
-
NO.Category / SolutionFeatures
-
DaVinci-MBI5762Common Cathode Fine Pitch0.8mm-2.6mm
