Macroblock’s Common Cathode Driving Architectures are Patented in the US
Patent no.: US 11,132,940,B2;
Patent no.: US 11,132,939,B2;
You can use Patent Public Search Basic of USPTO for more details
------------------------------------------------------------------------------------------------------------------------------------------
MBI5780Q (Patented) Specification
-
ItemsSpec.Content
-
01No. of Output Channel48
-
02Output Current per Channel0.1~15mA
-
03Sustaining Output Voltage7V
-
04Excellent Output Current Accuracy-between channels<±1.0％ (Max.)
-
05Excellent Output Current Accuracy-between ICs<±1.0％ (Max.)
-
06AEC-Q100
-
07Scan DesignUp to 90-scan
-
08Error Detection - LED Open
-
09Error Detection - LED Short
-
10Current Gain6-bit
-
11Dimming Method14/15/16-bit PWM
-
12RoHS Compliant PackageQFN88
-
13Major ApplicationsInteractive LED Matrix Display, Digital Cockpit Platform
