MBI6353Q is an advanced 48-channel high power constant current full-array local dimming (FALD) backlighting LED driver. The innovative architecture is designed to support up to 1:4 time-multiplexing and control up to 192 LED dimming zone applications using internal Pulse Width Modulation Dimming(P-DIM) and Analog Dimming(A-DIM) control with 12-bit color depth and extra 2-bit high luminance mode by zone to improve contrast ratio for HDR applications.
Both compulsory and real-time LED error open/short detection and protection are included during both start-up and regular operation. Besides, MBI6353Q also provides DC/DC feedback control, ghost elimination function, and over-temperature protection features.
MBI6353Q Specification
-
ItemsSpec.Content
-
01No. of Output Channel48
-
02Output Current per Channel4~100mA
-
03Sustaining Output Voltage24V
-
04Excellent Output Current Accuracy-between channels<±3.0％ (max.)
-
05Excellent Output Current Accuracy-between ICs<±3.0％ (max.)
-
06AEC-Q100
-
07Scan DesignUp to 4-scan
-
08Error Detection - LED Open
-
09Error Detection - LED Short
-
10Dimming Method12-bit PWM
12-bit Hybrid
10-bit PAM -
11Protection-OTP
-
12RoHS Compliant PackageQFN-68 8X8
-
13Major ApplicationsADB
