MBI6023 is a 3x4-channel, constant-current, PWM-embedded sink driver for LED strips. MBI6023 provides constant current ranging from 3mA to 45mA for each output channel and are adjustable with three corresponding external resistors. Besides, MBI6023 can support both 3.3V and 5V power systems and sustain 17V at output channels.
With Scrambled-PWM (S-PWM) technology, MBI6023 enhances pulse width modulation by scrambling the “on” time into several “on” periods to increase visual refresh rate at the same gray scale performance. Besides, the grayscale clock (GCLK) is generated by the embedded oscillator. Moreover, MBI6023 provides two selectable gray scale modes to trade off between image quality and transmission: 16-bit gray scale mode and 10-bit gray scale mode.
In addition, MBI6023 features a two-wire transmission interface to make cluster-to-cluster connection easier. To improve the transmission quality, MBI6023 provides phase-inverse output clock to eliminate the accumulation of signal pulse width distortion.
MBI6023 Specification
-
ItemsSpec.Content
-
01No. of Output Channel3x4
-
02Sustaining Output Voltage17V
-
03Supply Voltage3~5.5V
-
04Transmission Interface - Topology2-Wire
-
05Transmission Interface - Clock IntegrityClock Inversion
-
06Transmission Interface - Bi-directional
-
07Constant Output Current Range per Channel3~45mA
-
08Built-in LDO
-
09Error Detection - LED Open
-
10Error Detection - LED Short
-
11Error Detection - Wire Disconnection
-
12Thermal Protection
-
13Current Gain
-
14S-PWM16-bit
-
15Dot Correction
-
16PWM
-
17RoHS Compliant PackageSSOP24
QFN24 -
18Major ApplicationsLED strip, mesh display
