MBI6306Q Specification

• Items
  Spec.
  Content
• 01
  No. of Output Channel
  6
• 02
  Output Current per Channel
  0.1~10mA
• 03
  Sustaining Output Voltage
  16V
• 04
  Excellent Output Current Accuracy-between channels
  <±2.0％ (max.)
• 05
  Excellent Output Current Accuracy-between ICs
  <±3.0％ (max.)
• 06
  Scan Design
  Static
• 07
  Error Detection - LED Open
• 08
  Error Detection - LED Short
• 09
  Current Gain
  2-bit/Global
• 10
  Dimming Method
  8-bit PAM
• 11
  Dot Correction
• 12
  High Luminance
• 13
  Protection-OTP
• 14
  RoHS Compliant Package
  QFN-16 3x3
• 15
  Major Applications
  Digital Cockpit Platform
