Step-Down, 2.5A Dimmable LED Driver for Automotive Lighting

MBI6659 is a step-down constant current high brightness LED driver to provide a cost-effective design solution for interior/exterior illumination applications. It is designed to deliver constant current to light up high-power LEDs. With PWM control scheme, MBI6659 eliminates external compensation design and makes the design simple

The output current of MBI6659 can be programmed by an external resistor and dimmed via pulse width modulation (PWM) or DC voltage through EN pin to achieve higher efficiency linear current modulation.

MBI6659 features completed protection design to handle faulty situation s The startup function limits the inrush current while the power is switched on Thermal shutdown Thermal Foldback and Schottky diode short SDS ) guard the system to be robust and keep the driver away from being damaged which results from LED open-circuited, short-circuited, and other abnormal events.

MBI6659 Specification

  • Items
  • 01
    Buck/ Const. Frequency
  • 02
    Max. Output Current per Channel
  • 03
    Max. Sustaining Voltage
  • 04
    Supply Voltage
  • 05
    Switch on Resistance
  • 06
    Common Anode
  • 07
    Dimming Method
  • 08
    Protection - LED Open
  • 09
    Protection - LED Short
  • 10
    Protection - Thermal Shutdown
  • 11
    Protection - Start-Up
  • 12
    Protection - UVLO
  • 13
    Protection - OCP/OCL
  • 14
    Protection - Themal Fold-back
  • 15
    Protection - OTP Error FLAG
  • 16
    Protection - OCP Error FLAG
  • 17
    Soft Start-up
  • 18
    RoHS Compliant Package
  • 19
    Major Applications
    MR11, MR16, flood light, PAR light, wall wash light, stage light, panel light, emergency lighting, street light, tunnel lighting, high power LED lighting, automotive lighting
